There are not data on the limelight port

#1

Hello all,
I am debugging my own board with LMS7002M mounted on it. there is only 1.8V power supply for the LMS7002M, of course, innner LDOs are used. I only use the one RX channel to receive signal, the TX channels are closed. Currently, I find the digital RSSI changed with input analogue applitude varying. that shows the RXTSP module works fine. except the MCLK and IQsel_en signals are right in the FPGA side. the data lines are almost zeros except bit[9] of I channel, of course, even there is not input in the front LNA, the results almost is same.Now, when I changed the input from RxTSP(A/B to RNDGEN in the Limelight module, shown in the following block diagram. the results are same .


Meanwhile, I paste the ini setting in the following.
